YSX-200-01C
Nov 09, 2023
Long range acoustic device is designed for special armored vehicle use and comes equipped with a DC10V-30V power supply option. Thelong range acoustic device comprises control components, digital signal processing and amplification unit, two sets of high power speakers, a highly sensitive microphone, an integrated control system.
Specification
|
Maximum power |
200W |
|
Maximum peak sound pressure level (1m) |
142+2dB (1m) |
|
Maximum sound pressure level |
≥122+2dB (10m) |
|
Directivity |
Main lobe width≤±9°(-3dB,2KHz) |
|
Reverse Sound pressure level |
1181+2dB (1m) |
|
Maximum reverse sound pressure level |
190+2dB (10m) |
|
Speech intelligibility |
95% (100m, wind speed ≤2m/s) |
|
Volume adjustment levels |
Continuous adjustment |
|
Power supply options |
DC24V vehicle power, DC12V vehicle power |
|
Operating temperature |
-40℃ to 50℃ |
|
Weight of the main unit |
≤19Kg |
|
Dimensions of the main unit |
640*370*310 |
|
Installation method |
Vehicle - mounted |
|
Function |
Product functions: security signal, recording, dispersion signal, high definition call out, ambulance signal, fire signal, playback of recording and music, MP3 playback/FM reception, Bluetooth functions, multiple sound effects,and DSP anti howling function |
Application
