Portable Acoustic Speaker Device YSX-400-01B

Portable Acoustic Speaker Device YSX-400-01B

This product adopts broadband moving coil transducer for matrix design, which can clearly broadcast voice as well as realise high sound pressure level acoustic wave dispersal function, and is a non-contact, non-lethal soft kill weapon.

  • Fast Delievery
  • Quality Assurance
  • 24/7 Customer Service
Product Introduction

Well-known as one of the leading and professional manufacturers and suppliers of portable acoustic speaker device ysx-400-01b, we warmly welcome you to contact our factory to buy the high-end and quality equipment. We will offer you good after-sale service and fast delivery.



This product adopts broadband moving coil transducer for matrix design, which can clearly broadcast voice as well as realise high sound pressure level acoustic wave dispersal function, and is a non-contact, non-lethal soft kill weapon. The host structure is made of carbon fiber material, light weight, high strength and excellent weather resistance.



Strong directivity

The use of parabolic waveguide surface so that the directivity of the unit is more acute, to achieve directional transmission of sound waves.



High definition

According to the speaker frequency response characteristics of the built-in solid-state DSP sound multimedia player, making both good dispersion effect and good music effect.


High sound intensity

150±3 dB (@1m)



Main performance parameters:

Maximum peak sound pressure level

135±2dB (10M)

Maximum sound pressure level

≥122±2dB (10M)

Equipment frequency response characteristics

amplitude frequency response -11.3dB

Directivity

main valve width ≤ ±9° (-3dB, 2KHz)

Reverse sound pressure level

121±2dB (1M)

Reverse maximum sound pressure level

110±2dB (1M)

Voice transmission index

0.6 (at 400M, wind speed ≤2m/s)

Voice intelligibility

86.3% (at 100M, wind speed ≤2m/s)

Volume adjustment gear

no pole gear

Sound source centre from the ground

≥1.7M

Power supply

support for utility, car 24V, 12V power supply

Maximum power

400W

Working temperature

-40°C~50°C

Host weight

≤25Kg

Host size

620 * 620 * 235mm
