Low Power Consumption Superior Optical System LED Light LL108 Series

Low Power Consumption Superior Optical System LED Light LL108 Series

low power consumption superior optical system LED light LL108 series Features: Using high power Gen III leds light sources with reliable performance and low power consumption. Superior optical system, enabling excellent light forms and wide view angles. Flexible mountings, optional within...

Product Details

low power consumption superior optical system LED light LL108 series

Features:

Using high power Gen III leds light sources with reliable performance and low power consumption.

Superior optical system, enabling excellent light forms and wide view angles.

Flexible mountings, optional within surface mount and bracket mount.

Compact aluminum housing, good heat sink capability for heavy duty application.

Diversified combination options of different overall lengths are available.

Colors can be chosen from red,amber and blue based on your requests.

All options are available with DC12V or DC24V applications.

Inside standard flash patterns with maximum 25 options in the current design.

Can be designed to include flash patterns and modular combination if needed.


Model

LL108BH2

LL108BAH4

LL108BH6

LL108BH8

LL108AH12

L(mm)

205.3

316

568.1

749.5

900

W(mm)

36.5

36.5

36.5

36.5

36.5

H(mm)

35

35

35

35

35

Mounting

Permanent

Permanent

Permanent

Permanent

Permanent

Rated Voltage

DC12V/24V

DC12V/24V

DC12V/24V

DC12V/24V

DC12V/24V

Current draw

700mA

1.4A

2.1A

2.8A

2.8A

Rated Power

16W

24W

48W

64W

72W

Color options

Red,Blue,Amber, Clear

Red,Blue,Amber, Clear

Red,Blue,Amber, Clear

Red,Blue,Amber, Clear

Red,Blue,Amber, Clear

Net weight

0.68kg

0.94kg

1.45kg

1.94kg

2.15kg

Well-known as one of the leading and professional manufacturers and suppliers of low power consumption superior optical system led light ll108 series, we warmly welcome you to contact our factory to buy the high-end and quality equipment. We will offer you good after-sale service and fast delivery.
